MASCHINE Sequencer

Eight-channel trigger sequencer

(20 Votes)
1.1 (Updated 10 months ago)
4.1MB
June 08, 2016
Reaktor 6
Blocks User Blocks

DESCRIPTION

The MASCHINE Sequencer Block is an eight-channel trigger sequencer designed to control Blocks patches directly from your MASCHINE MK2 controller. Each channel has independent controls for the attributes DIVISION, DIRECTION, LENGTH, and START, making it easy to quickly create complex polyrhythmic patterns. The eight pattern slots allow you to store and recall patterns in their entirety. Patterns can be copied and pasted between slots by using the COPY and PASTE buttons.

Additionally, the MASCHINE Sequencer features a Euclidean pattern generator that can be used to populate a channel with an algorithmically generated sequence.

Although designed to be used in conjunction with the MASCHINE MK2 controller, all parameters are available in the software panel, allowing you to use the MASCHINE Sequencer without a MASCHINE MK2 controller.



The MASCHINE Sequencer works perfectly with the Niji Drums, an example patch is included with the download file. Download here:
http://www.native-instruments.com/en/reaktor-community/reaktor-user-library/entry/show/10151/

Please note: The MASCHINE Sequencer requires a specific controller configuration that you need to load onto your MASCHINE MK2 controller utilizing the Controller Editor software. Be aware that loading a new configuration will overwrite any unsaved changes made to your current controller configuration.

If you wish to keep the current state of your controller configuration, save your current configuration before loading the configuration required by the MASCHINE Sequencer.

How to setup the MASCHINE Sequencer for use with your MASCHINE MK2 controller:

1. Launch the Native Instruments Controller Editor application, go to File > Open Configuration and open the "Reaktor Blocks - Maschine Mk2.ncc" template.

2. Switch your MASCHINE MK2 controller to MIDI mode by pressing [SHIFT] + [CONTROL] on the controller.

3. Open the Audio and MIDI Settings in REAKTOR and go to the MIDI tab. In the Inputs pane, set the "Maschine MK2 Virtual Input" (OS X) / "Maschine Mk2 In" (Win) entry to "On". In the Outputs pane, set the "Maschine MK2 Virtual Output" (OS X) / "Maschine Mk2 Out" (Win) entry to "On".

You can now use your MASCHINE MK2 controller to play and program the MASCHINE Sequencer in Blocks.

COMMENTS  (57)

Lothar Heitz
3 months ago
With Maschine Studio it doesn't work ???? please how
Martin Bayer
4 months ago
Here's my version for Maschine MK1, works fine except for the lights. Just copied all settings from the Mk2 template in Controller Editor and had to shift some knobs: https://drive.google.com/open?id=0B6-PLu3Gh1moelJqc3IyNXI5UmM
Martin Bayer
4 months ago
+1 also from my side for MK1 support
Dmitry Savin
4 months ago
+1 for mk1 support! please!!
Leon Trimble
6 months ago
are you even listening? mkI support very much needed by many...
Paul Pringle
6 months ago
Mk1 support +1 please :)
Future Aztec Man
7 months ago
Hey there. Notice joseph perkins' comment two down. We are stuck. Here's a video https://www.youtube.com/watch?v=LnvVKMwWh7Y
Victor Carrillo
7 months ago
Trying to follow the directions below... {"Reaktor Blocks - Maschine Mk2.ncc" } this file is not located inside the Maschine Sequencer download folder. {*Reaktor Blocks - Maschine Mk2.ncm2} is inside the Maschine Sequencer download folder. Where do we find the "Reaktor Blocks - Maschine Mk2.ncc" that's in your step #1 ? Thank you.
joseph perkins
8 months ago
Does this one only work in standalone mode? the Kontrol F1 mod has an issue in Ableton. If this one works in Ableton then there's hope for the F1 version :)
Jason Chatzilias
8 months ago
MK1 support please.
oli fant
8 months ago
MK1 +1
RAW FN
10 months ago
MK1 +1. ....
Ian Cohn
10 months ago
Hi, does this work in Mk2 Mikro? Not coming up in the midi out list
w edmond
10 months ago
Sussed it. Correct setup in Cont Editor is: 1. Launch the Native Instruments Controller Editor application, select "Open" from the "Edit" drop down menu in the "Template" pane, and open the "Reaktor Blocks - Maschine Mk2.ncm2" (MASCHINE Mk2) / "Reaktor Blocks - Maschine Studio" (MASCHINE STUDIO) template.
w edmond
10 months ago
Mapping appears wrong in mk11. I also needed to rename the configuration file to .ncc before it would open.
Josh Bassett
10 months ago
MK1 version would be amazeballs.
Bryce Upright
10 months ago
Any idea what the 1.1 update changed?
Mario Krušelj
10 months ago
Makes no sense to have a block like this that doesn't work with all Maschine variants, IMHO...
Worwell _
10 months ago
Thank you NI. This is very cool.
Andreas Karperyd
10 months ago
is there a technical reason it don't work with the machine Mk1 ?. or just
MAURO VALERO
10 months ago
hey Matt.. I just installed maschine sequencer but I can't see it in reaktor on the list in reaktor blocks, I double check into my library but I don't see it
Andy D'arcy
10 months ago
Reaktor Blocks - Maschine Mk2.ncc where dp you find this or am i missing something
Frank Wiedmann
10 months ago
Does this sequencer work with machine mkII and REAKTOR standalone only or is there a way to get it to work with reaktor in a DAW like ableton? thnks
Emlyn Lucas
10 months ago
Please allow this to work on all Maschine Hardware. Thanks NI! Particularly Maschine Studio.
Worwell _
10 months ago
Micro please!
Rob Cosh
10 months ago
Thanks Deutsch Christophe - great to hear you are working on it!
michael matos
10 months ago
Studio support please!
Jens Porath
10 months ago
mk1 version pretty please with sugar on top!
adnan imami
10 months ago
NI thanks for this but come on don't neglect MK1 users we are old but not obsolete :(
deutsch christophe
10 months ago
I've made a MK1 version, everything is working, but the only thing i can't have for now is the "light-state-feedback" on the controller. someone got an idea how to make it ?
Heikki Rinkinen
10 months ago
Please someone hack this to work with MK1! Thank you.
Joey Valizan
10 months ago
It would be awesome if the division function supported odd numbers: 1/3, 1/5, 1/7. I haven't looked at its guts but is that possible?
deutsch christophe
10 months ago
I'm working on making the machine mk1 controller version guys...i'll upload it when its ok
Rob Cosh
10 months ago
+1 for Mk1 please!! This looks awesome. Major props to NI for having been great about backwards compatibility with Mk1 for a long time... please don't stop! :)
Solid State
10 months ago
Weird that it only supports MK2. Mikro, Studio and MK1 support please!
Victor Carrillo
10 months ago
hey Matt Cellitti, it's viktor. in less its been fixed, If your using Maschine 2 inside of a daw like Live 9, there was an issue specific to Reaktor plugins with-in {Maschine plugin(midi ch1)}. Were Reaktor would not reset its midi channel and was stuck on midi channel 1. Had to manually change the midi channel in reaktor on both levels. maybe something similar to what your experiencing.
deutsch christophe
10 months ago
+1 for machine mk1 please
kris northern
10 months ago
I followed the install directions and also updated all NI programs Machine Studio does not reflect what the Machine Sequencer is doing in Reaktor. Has anyone else gotten it to work?
Adam Guth
10 months ago
+1 Please let us know about Maschine Studio. Thanks!
Bryce Upright
10 months ago
Same issue here Matt
Christian Schneider
10 months ago
I was so looking forward to this. Please, please consider a Mk1 version. Thanks!!!
Klas Linder
10 months ago
Good!
Matt Cellitti
10 months ago
Some real issues with certain steps transmitting other MIDI/Note data...for instance, I began tweaking the example ensemble to have (2) MIX 4's instead of the "add" module. Now every time I hit Step 15 on the controller it automatically makes Ch 1 of the Mix 4 drop to zero. Any ideas? Big issues if you try to add a Note In block for triggering other Osc's as well....
saki sdrakas
10 months ago
perfect!
david elson
10 months ago
love this...
andy o donoghue
10 months ago
This might be exactly what I'm looking for, excited to try it out, will report back !!
Mark Ashworth
10 months ago
Can anyone confirm if this is working with Studio? Mine is not working as it should....
Rocky Durand
10 months ago
Make sure that you backup your existing Maschine Mk2 Templates in Controller Editor (FILE > SAVE CONFIGURATION), before opening the "Reaktor Blocks - Maschine Mk2.ncc". Otherwise you will wipe out all of your existing templates...
Martin Géč
10 months ago
+1 for Maschine MK1 version!
Konstantin Kaltenegger
10 months ago
please do a version for the mk1 ... i was so looking forward to this :/
Jason Ruddy
10 months ago
So I can't use this with my Maschine Studio - the step above Maschine?
Sander Baan
10 months ago
Believe this only works with Maschine MK2
Phil Durrant
10 months ago
I don't think it will work with the MK1 because, you need to load Maschine Mk2.ncc into the Controller Editor App,
Saint Louis
10 months ago
Does someone know if this will work with maschine MK1 hardware?
Martin Novak
10 months ago
Awesome! Thanks
GG.G SakabeaT
10 months ago
nice one thx
Paule
10 months ago
Ah, the missing file. Thankx!
